This circuit is a wide band monolithic Low Noise Amplifier with state of the art wide band, low noise and adjustable gain performance.
It is designed for a wide range of applications, from military to commercial communication and test instrumentation systems.
It is manufactured with a successfully space evaluated pHEMT process, 100nm gate length, via holes through the substrate, air bridges and electron beam gate lithography.
ESD protection on DC/RF is included in the product.
