Datasheet Download| Reference | Gain (dB) | P-1dB OUT (dBm) | Sat. Output Power (dBm) | PAE (%) | IP3 (dBm) | RF Bandwidth (GHz) | Bias (mA) | Case | Bias (V) | |
|---|---|---|---|---|---|---|---|---|---|---|
| min | max | |||||||||
The CHA8100-99F chip is a monolithic two-stage High Power Amplifier designed for X band applications. The HPA provides typically 11W output power, 40% power added efficiency and a high robustness on mismatched output. Moreover it includes:
The circuit is 100% DC and RF tested on wafer to ensure performance compliance.
This device is manufactured using a GaInP HBT process, including, via holes through the substrate and air bridges.
| Reference | Gain (dB) | P-1dB OUT (dBm) | Sat. Output Power (dBm) | PAE (%) | IP3 (dBm) | RF Bandwidth (GHz) | Bias (mA) | Case | Bias (V) | |
|---|---|---|---|---|---|---|---|---|---|---|
| min | max | |||||||||
