Datasheet Download| Reference | RF Bandwidth (GHz) | P-1dB IN (dBm) | LO Bandwidth (GHz) | IF Bandwidth (GHz) | Conv. Gain (dB) | LO Input Power (dBm) | Bias (mA) | Bias (V) | Case | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| min | max | min | max | min | max | |||||||
The CHM2179b98F is a monolithic single channel mixer, which integrates high quality Schottky diodes that produces low conversion loss and very low 1/f noise.
The circuit is designed for sensors system at W-band, such as automotive long range radar and industrial sensors.
The circuit is manufactured with a Schottky diode MMIC process, 1µm gate length, via holes through the substrate, air bridges and stepper lithography.
It is available in chip form.
| Reference | RF Bandwidth (GHz) | P-1dB IN (dBm) | LO Bandwidth (GHz) | IF Bandwidth (GHz) | Conv. Gain (dB) | LO Input Power (dBm) | Bias (mA) | Bias (V) | Case | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| min | max | min | max | min | max | |||||||
