The CHR2421-QEG is a monolithic multifunction dual channel receiver in K-Band which integrates low noise amplifiers and mixers providing an IF signal from DC to 1 MHz. All the active devices are self biased on chip.
The circuit is dedicated to sensors and also well suited for a wide range of microwave and millimetre wave applications and systems.
The circuit is manufactured with a pHEMT process, 0.25µm gate length.
It is supplied in a 24 leads RoHS compliant QFN4x5 package.
