Datasheet Download| Reference | RF Bandwidth (GHz) | Bias (mA) | Bias (V) | Case | LO Bandwidth (GHz) | IF Bandwidth (GHz) | Conv. Gain (dB) | LO Input Power (dBm) | Noise Figure (dB) | P-1dB IN (dBm) | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| min | max | min | max | min | max | ||||||||
The CHR3764-QEG is a multifunction monolithic circuit, which integrates a balanced cold FET mixer, a multiplier by two, and a RF LNA including gain control.
It is designed for a wide range of applications, typically ISM and commercial communication systems.
The circuit is manufactured with a pHEMT process, 0.25µm gate length, via holes through the substrate, air bridges and electron beam gate lithography.
It is supplied in RoHS compliant SMD package.
| Reference | RF Bandwidth (GHz) | Bias (mA) | Bias (V) | Case | LO Bandwidth (GHz) | IF Bandwidth (GHz) | Conv. Gain (dB) | LO Input Power (dBm) | Noise Figure (dB) | P-1dB IN (dBm) | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| min | max | min | max | min | max | ||||||||
